| Parametr |
Model | WSM1-520 | |
Ishlash | ||
Nominal yuk | KG | 2000 |
Forklift markazi (yuk mashinasi old tomoniga) | mm | 1450 |
Maks. Og'irlikni ko'tarish | KG | 3000 |
Yuklash markazi (yuk mashinasi old tomoniga) | mm | 500 |
Maksimal ko'tarish tezligi H2 | mm | 4950 |
Maks. Kengaytma masofasi L2 | mm | 2950 |
Maks. Haydash tezligi | Km/soat | 25 |
Maks. darajalilik | % | 25 |
Og'irligi | KG | 5000 |
Bom | ||
Bom NO | 2 | |
Ish vaqti | s | 10.5 |
Ishdan chiqish vaqti | s | 9.5 |
Uzatilish vaqti | s | 8 |
Qaytarilish vaqti | s | 12 |
Old aylanish vaqti | s | 6 |
Orqa aylanish vaqti | s | 5.5 |
O'zgaruvchan burchak | ° | -5 ～ 60 |
Hajmi | ||
Uzunlik (vilkalarsiz) L | mm | 4200 |
Kengligi W | mm | 1500 |
Balandligi H | mm | 2200 |
Old aylanma A | mm | 1400 |
G'ildirak bazasi B | mm | 2200 |
Orqa aylanadigan C | mm | 600 |
G'ildirak protektori (old/orqa) E | mm | 1200 |
Min.erni tozalash F | mm | 300 |
Kabina kengligi M | mm | 600（himoya ramka） |
Minimal burilish radiusi | ||
Ikki g'ildirakli rul | mm | 2800 |
To'rt g'ildirakli rul | mm | / |
Vilkalar hajmiL1*W1*H1 | mm | 1000*120*40 |
Vilkalar ramkasining kengligi N | mm | 1200 |
Standart | ||
Dvigatel modeli | LR4B3ZU | |
Ishlab chiqaruvchi | Yituo (Luoyang) dizel dvigateli | |
Nominal quvvat | 62,5 kVt/2200 ayl/daq | |
Emissiya | Ⅲ stantsiyasi | |
Transmissiya rejimi | Gidravlik uzatish | |
Vites (old/orqa) | 2/2 | |
Haydash rejimi | Old ikki o'qli harakatlanish | |
Rulda rejimi | Orqada ikkita o'qni boshqarish | |
Xizmat tormozi | Baraban turi | |
To'xtash tormozi | Mexanik | |
Shina (old/orqa) | 300-15/6.00-10 | |
Ixtiyoriy | ||
Dvigatel modeli | QSB3.9--C80-31 | |
Ishlab chiqaruvchi | Dongfeng Cummins | |
Nominal quvvat | 60 kVt / 2200 aylanish / min | |
Nominal moment | 350Nm/1600rpm | |
Emissiya | Stansiya Ⅲ /EI bosqichiⅢA | |
Transmissiya rejimi | Gidrostatik uzatish | |
Orqa (old/orqa) | 2/2 | |
Haydash rejimi | To'rt g'ildirakli haydash | |
Rulda rejimi | Mo'ynali kiyimlardan rul boshqaruvi | |
Xizmat tormozi | Ko'p diskli nam | |
To'xtash tormozi | gidravlik bo'shatish | |
Shina | 16/70-20-14PR/10PR | |
Dvigatel modeli | QSB3.9--C80-31 | |
